Desk - Top Switching Power Supply 12V 1.5A 18W / 12V 2A 24W Universal

Desk - Top Switching Power Supply 12V 1.5A 18W / 12V 2A 24W Universal

    • Desk - Top Switching Power Supply 12V 1.5A 18W / 12V 2A 24W Universal
    • Desk - Top Switching Power Supply 12V 1.5A 18W / 12V 2A 24W Universal
  • Desk - Top Switching Power Supply 12V 1.5A 18W / 12V 2A 24W Universal

    Product Details:

    Place of Origin: Shenzhen Guangdong China
    Brand Name: REEU
    Certification: ETL/CE/GS/PSE/KA/CCC/FCC
    Model Number: 18D/24D

    Payment & Shipping Terms:

    Minimum Order Quantity: 500pcs
    Price: negotition
    Packaging Details: white box+carbon
    Delivery Time: 15-20 days
    Payment Terms: T/T, L/C
    Supply Ability: 500,000pec per month
    Contact Now
    Detailed Product Description
    Output Voltage: 5-24VAC Input: 100-240V
    Burn-in: More Than 4 Hours Warranty: 2 Years
    Product Name: Desk-top Switching Power Supply DC Plug: 5.0x2.5/5.5x2.1
    AC Cable: 1.5m Standard Package: White Box + Carbon
    High Light:

    notebook ac adapter

    ,

    desktop power supply

    Desk top 12V 1.5A 18W 12V 2.0A 24W uniersal AC switching power adapter:



    Description:



    Input voltage:90-264VAC

    Input frequency:47--63Hz

    Output:12V1.5A,12V2A

    Color:black

    AC plug:US,EU,UK,CCC,PSE,KA

    AC cord:1.2m 1.5m 1.8m



    Specification:





    Input Rated input voltage 100-240Vac
    Input voltage range 90-264Vac
    Rated frequency 50-60 Hz
    Input frequency range 47-63hz
    Input AC current 2A
    Inrush current 20A Max
    Output Rated output voltage 12Vdc
    Rated output current 2000Ma
    Rated power 24W
    Ripple and noise 120mVp-p
    Standby power consumption 0.1W Max
    Turn-on 2S
    Hold-up 5mS
    OVP Yes
    OCP Yes
    Short Circuit prodection Yes
    Reliability Hi-pot 3000Vac
    Burn-In Full load at 115Vac for 4 hours
    Leakage current 0.25mA
    EMI standards FCC part 15
    RoHS compliant
    MTBF 50000hours
    Drop test Yes
    Insulation resistance Yes
    Environmental Operating temperature 0-40 degrees
    Operating humidity 20-90%
    Storge temperature -20-80 degrees
    Storge humidity 0-95%
    Safety approvals ETL FCC CE GS KA CCC SAA PSE
    Warranty 2 years



    Features:



    1. High efficiency:>83% at least

    2. Safety licences:main approvals of the world are available

    3. Burn -in:100% full load

    4. MTBF:50000 hours

    5. EFT:Follow IEC-61000-4-4

    6. ESD:The power is capable to withstand ESD test voltage at any pointaround the enclosure.



    Application:



    Video equipemnt TV box CCTV, router, set-top-box
    Audio equipment Speaker, microphone,recording device
    Communication device smart phone nootbook,tablet PC
    Household appliance air purifier, water purifier,solar panel
    Medical equipment cosmetic machine,glucose meter
    others PS4,segway,game player, electronic toys



    Competitive advantage:



    1. 2pcs free samples are available, we are free of shipping cost by UPS Fedex.



    2. High quality standard requested,we strictly follow up the quality management system as ISO9001.



    3. We have more than 400 first line works and 10 production lines that cause our lead time is 15 days after received the formal orders.



    4. In order to settle any problem adapter, we have set up the QE department to focuson the after sales service.



    5.Our customers come from worldwide, and our oversea sales team can quickly answer any question from customer within 24 hours.



    Why you can trust us?



    This adapter has pass ETL/CE/GS/PSE/EMC/KA/CCC safety approvals around the world and the quality is very good, also the efficiency can meet energy star requirements.

    The most important is our pricing and service is much better than other adapter suppliers.

    We have more than 15 years experience in this field and we are dedicated to the development and production of the power adapter. Our R/D team has 10-20 years experience and we have professional management in QC, purchasing and production.

    We are a adapter manufacturer and we have our own product ,but we also offer OEM to customers and at meantime, customization is available.

    Our monthly production capacity is 50,000 pcs adapters and we have four production lines,we have more than 30 QC/QA staff to make sure all adapters have passed each testing before packing.



    AC  DC universal power adapter
